THP series Flower Basket Tablet Press

THP series Flower Basket Tablet Press, Product Description

THP series Flower Basket Tablet Press Machine (Pill Press) is small continuous automatic tablet press which is one of the essential equipments for pressing granular raw materials into tablets or medicines taken with water in pharmaceutical, chemical, food, electronics industries. It can be used to press medicinal tablets, catalysts, candies, powder metallurgical parts electronics components, various tablets of pesticide and fertilizer etc. in small-batch production, laboratory and hospital. The machine can press special-shaped, ring like tablets of different kinds, and can also process the tablets of pesticide both sides are impressed trademarks, letters and simple patterns. THP single punch tablet press can also be used to produce big size tablet such as salt tablet/ tablet salt, TCCA tablets, fertilizer tablet/ fertilizer block/ fertilizer briquette, bath salt tablet, camphor tablet,moth ball, and so on.

THP series Flower Basket Tablet Press, Technical Parameters
Item THP-4  THP-10  THP-20
Maximum Pressure (KN)  40  100  200
Maximum Diameter of Tablet (mm)  30  40  60
Maximum Depth of Filling (mm)  25  45  45
Production Capacity (pc/min)  34-50  34-50  25-30
Motor (KW)  1.1  3.7  4
Overall Size (L*W*H) (mm)  685*565*1610  666*860*1824  1100*1040*2300
Net Weight  (kg)  520  750  1250
